16 17
1. Remove the backrest from the booster seat.
(See Removing the Backrest, page 19.)
2. Place the booster seat on the vehicle seat.
3. Set the child in the booster seat.
Make sure the child’s back is flat against the
vehicle seat,and the child’s bottom is flat against
the booster seat.
4.
Secure the child and booster seat to the vehicle seat.
Stretch the lap/shoulder belt across the child and
fasten the buckle.
5. Use the shoulder belt clip, if necessary.
If the shoulder belt does not properly lay midway
between the child’s shoulder and neck, attach and
adjust the belt clip (see Using the Shoulder Belt Clip,
page 20).
6. Check your work.
Make sure the lap belt is stretched low and snug
across the child’s hips, and fastened into the buckle.
The shoulder belt must cross the child midway
between his/her shoulder and neck.
Note: If the vehicle’s shoulder belt naturally crosses the
child’s shoulder, you do not need to use the shoulder
belt clip.
Lap Belt: Stretched
low and snug across the
child’s hips, and fastened
into the buckle.
Shoulder Belt: Must cross
midway between child’s
shoulder and neck. Use
belt clip, if necessary.
Child Requirements
Weight: 18 – 49.8 kg (40 – 110 lbs)
Height: 112 – 145 cm (44 – 57 inches)
Age: At least four years old
The tops of the child’s ears are below the
top of the vehicle headrest.
WARNING
Installation Checklist
Using Your Booster Seat
Without the Backrest
The shoulder belt MUST NOT cross the child’s neck or fall
off the child’s shoulder. If you can not adjust the shoulder
belt to properly lay midway between the child’s shoulder
and neck, try another seating location or do not use the
booster seat.
IMPORTANT
Always secure the booster seat with the vehicle seat belts
when not occupied. An unsecured booster seat can fly into
and injure other occupants in the event of a crash.
To Next Page
