4 5
3. Push four adjustment bumpers
D
into the corners of the gate frame
A
or the frame extension
B
.
NOTE: Make sure the adjustment
bumpers are pushed all the way in.
4. Position gate
A
on floor in
center of opening, making sure
that it is straight up and down
(90º to the floor).
NOTE: Adjustment bumpers
may mark some mounting
surfaces.
NOTE: If not installing gate at
top of stairs, go to step 8.
Distance between gate frame and door frame
should be equal on both sides, and NEVER exceed
2.75 in. (6.9 cm). If 2.75 in. (6.9 cm) is exceeded,
move to the next configuration on page 2.
Mounting Cap InstallationGate Assembly
5. Peel backing off one side of adhesive
pad
G
. Adhere pad to outside of
mounting cap
F
, as shown.
Peel backing off other side of adhesive
pad, and place mounting cap over end
of adjustment bumper
D
.
NOTE: Make sure gate stays straight up
and down (90º to floor) and in center of
door frame during this process.
Slide adjustment bumper
D
out of
gate frame toward door frame, until
mounting cap sticks to door frame.
Repeat this for other three mounting
caps.
6. Once all four mounting caps are in
place remove gate from opening in
order to secure mounting caps to
door frame with supplied screws
I
.
Tighten all four screws securely with
handheld Phillips screwdriver, but do
not overtighten.
NOTE: If mounting to drywall, mark
center of mounting caps. Pull mounting
caps off wall. Drill holes and insert wall
anchors
H
. Secure mounting caps with
screws. Tighten all four screws securely
with handheld Phillips screwdriver, but
do not overtighten.
7. Position gate
A
on floor in line with
mounting caps.
NOTE: If not installing gate at top of
stairs, go to step 8.
Gate Installation
Mounting caps MUST be installed
to use gate at top of stairs.
WARNING
WARNING
D A
D
A
D
D D
2.75 in. (6.9 cm)
Maximum
G
F
D
D
I
F
H
To Next Page
