2030 acoustic axis
The 2030 is an active 3-way speaker. This means that monitor placement slightly differs from a 2-way system.
The acoustic axis of the 2030 is located at the point directly between the tweeter and midrange driver.
Please see the diagram below for the acoustic axis point.
ACOUSTIC AXIS POINT
ACOUSTIC AXIS POINT
X
X
