connecting your speakers
Before you connect and turn on your Event 2030 speakers, ensure the Gain
level on the rear of the speaker is set to the lowest setting and the HF shelf
and LF shelf dials are both set to zero. If too much input signal is present,
the amplifiers may overload. Ensure the power switch is also turned off.
Next, connect your monitors via the XLR input located at the back of the
speaker. Use only good quality input connectors having industry standard
dimensions. If you require an input type other than XLR such as RCA or
TRS, you will require an adaptor to connect your speakers. However Event
strongly recommends using the XLR balanced input wherever possible for
a higher quality signal.
Check that your voltage selector has been configured to the correct
setting for your location. If your speaker is set at an incompatible
voltage, it will be necessary to switch the voltage selector and change the
fuse type.
If at all unsure of how to complete this process, Event strongly recommends
you contact qualified service personnel to switch the fuse. Once voltage
is correctly configured, connect your 3-Pin IEC AC connector from the
monitor to an AC power socket.
Your 2030 monitors are now ready to turn on. Adjust the Gain setting
as necessary to achieve a suitable level, leaving enough headroom for
control through your signal source.
