Eventide H90 Harmonizer - Page 11

Dual Routing
Quick Knob 1
Turn to change Routing position
for Presets and on
Paths 1 and 2. (See table)
Press to Swap Presets and .
Dual Routing enables two
independent stereo signal paths
and utilizes an alternate set
of Program Lists.
Path 1: Inputs and Outputs 1/2
Path 2: Inputs and Outputs 3/4
NOTE: When using H90 with four
cable method or pre/post in an
amp FX loop, Dual Routing is
strongly recommend.
9
Footswitches
Press any Footswitch to exit Routing Mode.
Footswitch LED Buttons
Press to Active/Bypass , , or .
Dual Routing in Select Mode.
Presets
and in Series on Path 1.
Preset
on Path 1, Preset on Path 2.
Routing
Path 1 Series
Path 1 Parallel
Pre/Post
Path 2 Parallel
Path 2 Series
Path 1
Series
Parallel
Preset A
Thru
Thru
Path 2
Thru
Thru
Preset B
Parallel
Series
Dual Positions
