INSTALLATION
This appliance comes with a number of parts which must be assembled to the main body before use. Check each
part is present & in good condition before proceeding.
1.
1. Fit one pin stopper into the axle. Place one wheel onto the axle and align the groves in the back of the
wheel over the pin. Fix wheel into place with one screw & push the screw cover into the centre of the
wheel. Push a spacer over the other end of the axle up to the pin & wheel.
2. Push the axle assembly through the supplied hole
in the appliance (at the front of the HSE151W &
HSE201W as shown, or rear of the HSE152W &
HSE202W). Push the second spacer over the axle
and fit the second pin stopper. Place the second
wheel onto the axle and align the groves in the
back of the wheel over the pin. Fix wheel into
place with one screw & push the screw cover into
the centre of the wheel.
1
2
3
6
4
5
1
