Everdure OBES63 - Troubleshooting Fan Problems; Fan Hitting Cover or Noisy; Fan Not Working

EVE
Electrical component problems
TROUBLE SHOOTING
Fan hitting its cover / working noisy
REMOVE THE FAN COVER.
PUSH BACK THE FAN WINGS AND
REPLACE THE COVER.
DOES IT STILL HIT TO COVER ?
CHANGE THE FAN COVER. DOES IT
SOLVE THE PROBLEM?
Fan problems
YES
Fan not working
IS THE WIRING OF FAN MOTOR
CORRECT ACCORDING TO THE
WIRING DIAGRAM ?
THE FAN SHOULD NOT HIT / OR BE
LOCKED ONTO THE FAN COVER.
YES
NO
CORRECT THE WIRING OF FAN MOTOR
PLEASE SEE :
FAN HITTING ITS COVER
NO
NO
CHANGE THE FAN.
DOES IT SOLVE THE PROBLEM?
NO
CHANGE THE FAN MOTOR
WHEN OVEN SWITCH TURNED ON,
CAN YOU MEASURE VOLTAGE AT
FAN MOTOR ?
CHECK IF THE FAN MOTOR ASSEMBLY
SCREWS ARE FIXED CORRECLTY.
PROBLEM SOLVED ?
CORRECT THE WIRING OF OVEN
SWITCH - see circuit diagram
CONTROL THE WINDINGS OF FAN
MOTOR WITH OHMMETER.
ARE MOTOR WINDINGS DAMAGED?
YES
YES
CHECK IF THE ROTOR GOT LOCKED.
CORRECT THE POSITION
IF STILL GOT PROBLEM ;
CHANGE OVEN SWITCH
NO
NO
MODELS: OBES61
OBES62
OBES63
SERVICE MANUAL BUILT IN ELECTRIC OVENS
