5.4.3 Testing mode selection
The testing mode (RMS or DC) can be set as follows:
1. Press "HOLD" firstly to enter the steady state, then press "RUNNING" to enter the
setting state. Windows A&B display the input testing mode of in mode, and windows
E&F display the input testing mode of out mode.
2. The current input testing model can be showed in window C and press " " to
switch it. Also, the current output testing model can be displayed in window G and
press "" to switch it.
3. When the instrument is under setting state, press "FUNCTION" to confirm or press
"HOLD" to confirm and exit.
NOTES: This setting is specially for state characteristic test, it has power-down
protection function, and will pop up the current input&output testing mode
automatically after restarting the instrument.
