1.3 Specifications
Pickup Device 1/3” SONY Super HAD CCD II
Video Format NTSC or PAL
Scanning System NTSC: 525 TVL, 60 fields/sec.
PAL: 625 TVL, 50 fields/sec.
Picture Elements 768 x 494(NTSC) ; 752 x 582 (PAL)
Horizontal Resolution 520 TV Lines
Sensitivity 0.08 Lux / F=1.2(IR Off), 0 Lux (IR On)
S/N Ratio Over 48 dB (AGC Off )
Electronic Shutter 1/50 (1/60) ~ 1/100,000
Lens Type Vari-focal lens: f=2.9~10mm, f=9~22mm
Back Light Comp. Yes
Auto Gain Control Yes
Auto White Balance Yes (2500
o
K ~9000
o
K)
True Day/Night Yes
Gamma Correction 0.45
Video Output BNC 1.0Vp-p, 75ohm
Sync. Mode Internal Sync.
IR LED Lifespan 20,000 hours
Power Source 12VDC/24VAC
Power Consumption 12VDC:9W max. (Heater ON & IR LED ON)
24VAC:9.5W max. (Heater ON &IR LED ON)
Dimensions 116.97mm(W) x 144.07mm(H) x 138.9mm(D) ;
4.6”(W) x5.7”(H) x 5.5”(D)
Weight 1.15kg/2.54lbs
Operating Temperature -40°C to +50°C ; -40 to 122 ℉℉(20%~80% Humidity)
IR Distance 30M / 98 ft.
IR Wavelength 850nm
Vandal Resistant Yes
Weatherproof IP66
Certifications FCC/CE
