SPECIFICATIONS
Pickup Device 1/3'' SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System
NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec
Picture Elements 768 x 494(NTSC) ; 752 x 582(PAL)
Horizontal Resolution 560TVL
Sensitivity 0.5Lux/F=1.2
S/N Ratio Over 48dB(AGC off)
Electronic Shutter 1/50(1/60)~1/100,000
Lens Type
Vari-focal lens, Auto Iris
f= 2.9~10mm
f=3.8~9.5mm
f=9~22mm
Back Light Comp. ON/OFF Switch
Auto Gain Control ON/OFF Switch
Flickerless ON/OFF Switch
Auto White Balance Yes
Gamma Correction 0.45
Video Output
2 video outputs
BNC 1.0Vp-p, 75ohm
Additional testing video output 1.0Vp-p, 75ohm
Sync. Mode Internal Sync
Power Source 12VDC/24VAC
Dimensions 108(O.D) x 80(D) mm ; 4.3"(O.D) x 3.1"(D)
Weight 0.3 kg ; 0.7lbs
Operating Temperature 0°C~40°C ; 32°F~104°F (20%~80% Humidity)
