EverFocus ED710 - Specifications; Environmental and Power Details

ED710/730 Ultra 720+ TVL Dome Camera
16
5. Specifications
Specifications and designs are subject to change for improving the functionality of this product
without notice.
P/N
ED710
ED730
Pickup Device
1/3” Sony Exview HAD II 960H High Sensitivity Interline CCD
Video Format
NTSC or PAL
Picture Elements
1020 x 508 (NTSC) / 1020 x 596 (PAL)
Effective Pixels
976 x 494 (NTSC) / 976 x 582 (PAL)
Scanning System
2:1 Interlace
Horizontal Resolution
720+ TVL
Sensitivity
0.05 Lux native from sensor
0 Lux with IR on
0.05 Lux native from sensor
S/N Ratio
Over 50 dB (AGC OFF)
Electronic Shutter
1/60(1/50)~1/100,000s
Video Output
BNC 1.0Vp-p 75Ω
Gamma Correction
0.45
Lens Type
2.8-12mm DC Iris
Lens Option
Varifocal
BLC
OFF/BLC/HS BLC Selectable
Gain Control
Low light auto,bright light auto,manual selectable
White Balance
ATW/One Push/User2/Anti-Crawl/Manual/Push Lock
Sync Mode
Internal(plus Anti-Chroma Crawl White Balance option)
Day/Night
Auto
True D/N with ICR，Auto
IR LED
N/A
18 Units
IR Wave Length
N/A
850nm
IR Distance
N/A
Up to 30m/100ft.range(depending
on scene IR reflectivity)
OSD Menu
Multiple Functions
OSD Languages
English,Spanish, Portuguese, German, Russian, Japanese, Chinese,
French
Digital Noise Reduction
Y/C, Y, C, OFF
ATR
On/Off(3 levels each adjustable for luminance and contrast)
Wide Dynamic Range
On/Off(3 levels each adjustable for luminance and contrast)
Mirror
Off/On
Motion Detection
Off/On for 4 selectable zones (On screen indication on alarm)
Privacy Mask
Off/On for 8 selectable zones
Environmental
Indoor
Power Source
12VDC/24VAC
Power Consumption
12VDC:140 mA,2W max.;
24VAC:2W max.;
IR on (12VDC:300mA, 4W max.
24VAC:4W max.)
Operating Temperature
-10°C~50°C / 14°F~122°F
Humidity
Less than 80%
Dimensions(in/mm)
133 x 96mm / 5.24 " x 3.78"
Weight(lbs/g)
0.75lbs /340g
0.79lbs /360g
Certifications
CE/FCC/RoHS
