ED710/730 Ultra 720+ TVL Dome Camera
6
1.2 Features
 Ultra resolution of over 720 horizontal TV lines for astounding image quality
 Exview HAD CCD II delivers amazing ultra high sensitivity of 0.05 lux – very low
light sensitivity without DSS low light boost - Zero Ghosting guaranteed
 Vari-focal 2.8~12mm DC iris lens to capture the desired field of view
 18 IR LEDs for 30m/100ft. range -depending on scene IR reflectivity (for ED730)
 Provides 2D- Noise Reduction to improve picture clarity while enabling DVRs to improve
disk storage utilization
 Adaptive Tone Curve Reproduction (ATR)/Digital Wide Dynamic Range expansion to
deliver properly exposed images despite unbalanced lighting in the scene
 Easy to use OSD setup menu
 Compact size for discreet sureillance
 The flexible angle viewing with its 3 Axis rotation design allows wall or ceiling mounting
 Easy lock installation by screwing the base plate to the surface and then locking the
camera to the base plate without mounting screws
2. Cable Description
No.
Name
Descriptions
1
Power Cable
Connects to a 12VDC or 24VAC power source.
2
Video Output
Connects to a DVR or monitor, using a 75 Ohm BNC-type
coaxial cable.
3
Test Lead
Connects to a monitor for setting image aim and focus.
4
DC Power Pigtail Cable
Optional power pigtail cable. The red wire is positive (+);
while the black wire is negative (-).
