4. Configuration in the OSD Menu
You can use the function buttons on the rear panel of the camera body to configure camera settings
in the OSD menu:
No.
Main
Sub Menu
Sub Menu / Function
1
Lens
Auto*
Type
DC*
Mode
AUTO*, Open, Close
Speed
0-255 (default=80)
Manual
2
Shutter
AGC
Auto*
High
Luminance
Mode
Shut + Auto Iris, Auto Iris*
Brightness
0-255 (default=24) <ED710>
0-255 (default=28) <ED730>
Low
Luminance
Mode
AGC*, Off
Brightness
x0.25, x0.50*, x0.75, x1.00
Manual
Mode
Shut+AGC
Shutter
1/60*, 1/100, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
AGC
6.00*, 12.00, 18.00, 24.00, 30.00, 36.00, 42.00,
44.80
3
White
Balance
ATW*
Speed
0-255 (default=239)
Delay CNT
0-255 (default=16)
ATW Frame
x0.50, x1.0, x1.5, x2.0*
Environment
Indoor*, Outdoor
Push
User1
B-Gain
0-255 (default=29)
R-Gain
0-255 (default=34)
User2
B-Gain
0-255 (default=45)
R-Gain
0-255 (default=26)
Anti CR
Manual
Level
24-90 (default=58)
Push lock
4
Back Light
Off* / BLC / HLC
5
Adjust
Mirror
Off* / On
Brightness
0-255 (default=0)
Contrast
0-255 (default=128)
Sharpness
0-255 (default=128)
