Building in
Dimensions of the recess
Height of housing mm 1780
Depth of housing mm 550
Width of housing mm 560
It is necessary that the cabinet has a
ventilation recess with the following
dimensions :
Depth 50mm
Width 540 mm
For appropriate venting, follow indications
in the figure.
Push the appliance into the housing
until stop strip (A) touches the kitchen
unit.
Press in the joint covers between the
appliance and the kitchen furniture (only
on the side without hinge)
Open the door and push the appliance
against the side of kitchen furniture
opposite to that of appliance
hinges. Fasten the appliance with 6
screws provided in the kit included with
the appliance. Snap vent grille (C) and
hinge cover (D) into position.
