Part Description Qty Part Description Qty
101 Computer 1 503 Transportation Wheel 2
102 Console Housing - Upper 1 504 Fold Holder 1
103 Console Housing - Bottom 1 505 Fold Holder Wheel 1
104 Water Bottle Holder 2 506 10mm Foot Cushion 4
105 Safety Key Base 1 507 Upright Cover - LL 1
106 Safety Key 1 508 Upright Cover - LR 1
509 Upright Cover - RL 1
201 Handle Bar 1 510 Upright Cover - RR 1
202 Upright - Left 1
203 Upright - Right 1 601 Running Belt 1
204 Hand Pulse Sensor 2 602 Side Rail 2
205 Power Switch Plate 1 603 End Cap - Left 1
206 Power Switch 1 604 End Cap - Right 1
207 Power Breaker 1 605 Running Deck 1
208 Electric Outlet 1 606 Cushion Pad 8
209 Hand Pulse Sensor Cover - Upper 2
210 Hand Pulse Sensor Cover - Bottom 2 701 ø4x15mm Screw 40
211 Power Switch Plate Base 1 702 Rail Guide 8
212 5 Pin Wire 2500mm 1 703 M8x10mm Bolt 2
213 2 Pin Wire 1900mm 1 704 M8x18mm Bolt 2
214 Handle Bar Cover - Left 1 1 705 M8x42mm Bolt 4
215 Handle Bar Cover - Left 2 1 706 ø4x19mm Screw 2
216 Handle Bar Cover - Right 1 1 707 M8x39mm Bolt 2
217 Handle Bar Cover - Right 2 1 708 M12x85mm Bolt 2
216 Handle Bar Cover - Right 1 1 709 M4x12mm Screw 3
217 Handle Bar Cover - Right 2 1 710 M10x59mm Bolt 2
711 M6x45mm Bolt 3
301 Main Frame 1 712 ø4x19mm Screw 16
302 Front Roller 1 713 M8x25mm Bolt 8
303 Front Roller Shaft 1 714 M5x14mm Bolt 4
304 Rear Roller 1 715 M8x47mm Bolt 1
305 Rear Roller Shaft 1 716 Motor Bolt 1
306 Control Board 1 717 Motor Cushion 1
307 Rear Foot Frame 1 718 Washer 2
308 Rear Foot Frame End Cap 4 719 M10x116mm Bolt 1
309 ø22 x ø10 End Cap 2 720 M8x12mm Bolt 2
721 ø8 Washer 13
401 Motor 1 722 ø10 Washer 3
402 Motor Holder 1 723 M10 Nut 3
403 Belt 1 724 M8 Nut 4
404 Motor Hood - Upper 1 725 M8x35mm Bolt 1
405 Motor Hood - Bottom 4 726 M8x50mm Bolt 1
727 ø3.5x15mm Screw 9
501 Base Frame 1 728 M8x45mm Bolt 2
502 Transportation Wheel Cover 2
Exploded Diagram Parts List
