10 Installation Instructions
5.1.3 Position
1. The unit has been designed for vertical or tilted backwards by max. 15°
installation.
2. Do not install the Eversol forwards.
3. Never install it horizontally.
4. Installing at eye level makes it easier to operate and read the display.
5.2 Installing the inverter
Installing procedure:
a) Drilling holes
Drill four holes for the screws at the selected installation position. The space between
every two holes is shown in the figure below. Keep drilling vertical to the wall, and
don’t shake the drill to avoid holes tilting. The depth of the holes must be the same
and in the range of 55 mm ~ 60 mm. After removing the dust in the four holes,
measure the net depth of the holes. If the depth is deeper than 60 mm or less than 55
mm, the expansion tubes wouldn’t be installed and tightened.
