7. Before mounting the main body, ensure the waterproof cover of the Control box
has been secured back if it was removed earlier.
8. To mount the main body, hinge the front cover tabs over the top edge of the
back cover and carefully push the base of the siren cover into place. Secure the
main body in place by refitting the fixing screw in the bottom edge of the cover.
Do not over tighten the screw as this could damage the thread.
IMPORTANT: Ensure that the rear tamper switch is closed when the main body is
fitted (i.e. listen for the switch to click). If the switch does not close, this will prevent
the Siren from operating correctly. If necessary, remove the main body again and
adjust the screw on the back cover tamper plunger to ensure the switch closes
when the siren is secured in position.
Note: removing the main unit from its back plate will cause the Tamper alarm to
sound. Quickly disarm the alarm panel if this happens.
9. Upon completion of mounting the main body on the wall, the Strobe LED will
flash two times as an indication of normal operation.
Status indication
LED flash every 2
seconds
About to learn the
ID code by
pressing the
learning button
LED Illuminates
when pressing the
learning button
within 3 seconds.
LED flashes every
0.5 seconds by
pressing the
learning button for
more than 3
seconds
Under learning
the ID code
LED flashes every
0.5 seconds
repeatedly
Success in
learning the ID
code
LED illuminates for
0.5 seconds then
extinguishing
Failure learning
the ID code
LED flashes 3
times rapidly(0.1
sec. on/0.1 sec.
off)
LED illuminates
when pressing the
learning button.
LED extinguishes
after successful
Fit two 30mm fixing screws in
the top holes leaving
approximately 10mm of the
screw protruding
Secure back cover using
two 25mm fixing screws at
the bottom
To Next Page
