2. GENERAL CHARACTERISTICS
3. ELECTRICAL SYMBOLS
Display LCD, 6000 counts updates 2/sec
LCD size 30 x 49 mm (1.2 x 1.9 in)
Polarity Indication “-” displayed automatically
Over-range Indication “OL” displayed
9V NEOA 1604，6F22 equivalent
Low Battery Indication
Storage Temperature
-10°C to 50°C (14ºF to 122ºF),
less than 85%RH
Operation Temperature
0°C to 40°C (32ºF to 104ºF),
less than 80%RH
Battery Type
42mm (1.6 in)Clamp Open Jaw
245×66×45mm (9.6×2.6×1.8 in)Dimension(H×W×D)
334g (11.8oz)Weight Approx
“ ” displayed
True-RMS ACV ACA measure
DC (Direct Current).
AC (Alternating Current)
DC or AC
Important safety information
Low battery
Diode
Continuity test
Refer to the manual
Dangerous voltage maybe present
Earth ground
Auto RangeAUTO
-4-
CelsiusºC
