EVGA Supernova G5 Series User Manual

13
Deutsch
650W / 750W / 850W / 1000W GOLD
Netzteil Bedienungsanleitung
SuperNOVA 650/ 750/ 850/ 1000G5 Kabelkonfiguration
Modularer
Steckverbinder
Stecker pro Kabel Kabelmenge
MB ATX 24-Pin x 1 1
CPU1
VGA1
VGA2
SATA1
SATA2
PERIF
Molex 4-Pin x 4
1
FDD
Molex to FDD Adapter
1
MB ATX 24-Pin x 1 1
CPU1
CPU2
VGA1
VGA2
VGA3
VGA4
SATA1
SATA2
SATA3
PERIF Molex 4-Pin x 4 1
FDD Molex to FDD Adapter 1
650 G5
850 G5
750 G5
EPS/ATX12V 8(4+4)-Pin x 1 2
PCI-E 8(6+2)-Pin 2
PCI-E 8(6+2)-Pin x 2 2
EPS/ATX12V 8(4+4)-Pin x 1
1
PCI-E 8(6+2)-Pin
1
SATA 5-Pin x 3 2
SATA 5-Pin x 3 3
PCI-E 8(6+2)-Pin x 2
MB ATX 24-Pin x 1 1
CPU1
CPU2
VGA1
VGA2
VGA3
VGA4
SATA1
SATA2
SATA3
PERIF Molex 4-Pin x 4 1
FDD Molex to FDD Adapter 1
1000 G5
EPS/ATX12V 8(4+4)-Pin x 1 2
PCI-E 8(6+2)-Pin x 2 4
SATA 5-Pin x 4 3
1
Modularer
Steckverbinder
Stecker pro Kabel Kabelmenge
Modularer
Steckverbinder
Stecker pro Kabel
Kabelmenge

EVGA Supernova G5 Series Specifications

General

Form Factor	ATX
Series	Supernova G5
Efficiency Rating	80 PLUS Gold
Fan Size	135mm
Warranty	10 Years
Fan Bearing Type	Fluid Dynamic Bearing
Input Voltage	100-240V
Input Frequency	50-60Hz
Operating Temperature	0°C to 50°C
Modular	Full
Maximum Power	650W, 750W, 850W, 1000W
Protections	OVP, UVP, OPP, SCP, OTP, OCP
