EVGA Supernova G5 Series User Manual

l
7
English
650W / 750W / 850W / 1000W GOLD
Power Supply User Manuall
Dimensions: 86mm (H) x 150mm (W) x 150mm (L)
Protection: Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection (SCP),
Over Power Protection (OPP), Over Current Protection (OCP), Over Temperature Protection (OTP).
SuperNOVA 650/ 750/ 850/ 1000G5 Specifications
+50°C ambient @ full load
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 10-5A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
24A 24A 54.1A 0.5A 3A
120W 649.2 W
6W 15W
650W @ +50°C
+50°C ambient @ full load
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 10-5A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
24A 24A 62.5A 0.5A 3A
120W 750W
6W 15W
750W @ +50°C
SuperNOVA 750 G5
SuperNOVA 650 G5
+50°C ambient @ full load
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 12-5A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
24A 24A 70.8A 0.5A 3A
120W 849.6W
6W 15W
850W @ +50°C
+50°C ambient @ full load
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 15-8A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
24A 24A 83.3A 0.5A 3A
120W 999.6W
6W 15W
1000W @ +50°C
SuperNOVA 1000 G5
SuperNOVA 850 G5

EVGA Supernova G5 Series Specifications

General

Form Factor	ATX
Series	Supernova G5
Efficiency Rating	80 PLUS Gold
Fan Size	135mm
Warranty	10 Years
Fan Bearing Type	Fluid Dynamic Bearing
Input Voltage	100-240V
Input Frequency	50-60Hz
Operating Temperature	0°C to 50°C
Modular	Full
Maximum Power	650W, 750W, 850W, 1000W
Protections	OVP, UVP, OPP, SCP, OTP, OCP
