EVGA Supernova G5 Series - Supernova 650; 750; 850; 1000 G5 Cable Configuration

6
English
650W / 750W / 850W / 1000W GOLD
Power Supply User Manual
SuperNOVA 650/ 750/ 850/ 1000G5 Cable Configuration
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1 1
CPU1
VGA1
VGA2
SATA1
SATA2
PERIF
Molex 4-Pin x 4
1
FDD
Molex to FDD Adapter
1
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1 1
CPU1
CPU2
VGA1
VGA2
VGA3
VGA4
SATA1
SATA2
SATA3
PERIF Molex 4-Pin x 4 1
FDD Molex to FDD Adapter 1
650 G5
850 G5
750 G5
EPS/ATX12V 8(4+4)-Pin x 1 2
PCI-E 8(6+2)-Pin 2
PCI-E 8(6+2)-Pin x 2 2
EPS/ATX12V 8(4+4)-Pin x 1
1
PCI-E 8(6+2)-Pin
1
SATA 5-Pin x 3 2
SATA 5-Pin x 3 3
PCI-E 8(6+2)-Pin x 2
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1 1
CPU1
CPU2
VGA1
VGA2
VGA3
VGA4
SATA1
SATA2
SATA3
PERIF Molex 4-Pin x 4 1
FDD Molex to FDD Adapter 1
1000 G5
EPS/ATX12V 8(4+4)-Pin x 1 2
PCI-E 8(6+2)-Pin x 2 4
SATA 5-Pin x 4 3
1
