20
Using the MFE Outboard
TILTING
IMPORTANT: Use the tilt grip to tilt the out-
board. Do not use the tiller handle as a lever.
Tilt UP
Move tilt/run lever to TILT position.
1. TILT position
Grasp tilt strap or tilt grip on engine cover and
tilt outboard to the full tilt position.
1. Tilt grip
Tilt support will automatically engage.
Tilt DOWN
Move tilt/run lever to RUN position.
1. RUN position
Grasp tilt grip on engine cover and raise out-
board slightly.
Tilt support will automatically disengage.
Slowly lower outboard to its normal operating
position.
TILT SUPPORT BRACKET
Engage
Raise the outboard to full TILT position. Push
tilt support bracket to “lock” position.
1. Tilt support bracket – lock position
WARNING
While outboard is tilted, leave tilt lever
in the TILT position. When the tilt/run
lever is in the RUN position, tilt support
can release unexpectedly and allow
outboard to drop, creating a risk of
serious personal injury or loss of con-
trol.
1
1
1
1
