PARTS LIST
#.
DESCRIPTION
REMARK
QTY
#.
DESCRIPTION
REMARK
QTY
1 MAIN FRAME 1 38 FIXING BOLT 2
2 BASE FRAME 1 39
LOCK NUT
M6 8
3 LEFT UPRIGHT 1 40
LOCK NUT
M8 8
4 RIGHT UPRIGHT 1 41 BOLT M8*16 10
5 COMPUTER BRACKET 1 42 BOLT
M8*25 L15
4
6 MOTOR BRACKET 1 43 SCREW ST4.2*16 2
7
BASE FRAME TURN
AXES
2 44
BOLT
M8*40 L20
6
8 FRONT ROLLER 1 45
BOLT
M8*50 L20
2
9 REAR ROLLER 1 46
BOLT
M10*55 2
10 CYLINDER 1 47
BOLT
M6*45 1
11
WRENCH W/SCREW
DRIVER
S=13, 14, 15
1 48
BOLT
M6*55 2
12
5#ALLEN WRENCH
5mm 1 49 BOLT M8*35 5
13 PULLING PIN 1 50
BOLT
M8*45 1
14 PULLING PIN SPRING 1 51
BOLT
M6*35 8
15 PULLING PIN COVER 1 52
BOLT
M3*8 2
16 MOTOR TOP COVER 1 53
BOLT
M5*8 7
17 BOTTOM BOARD 1 54
BOLT
M6*16 4
18
COMPUTER TOP
COVER
1 55 SCREW ST2.9*6.5 19
19
COMPUTER BOTTOM
COVER
1 56
SCREW
ST4.2*12 33
20 COMPUTER PANEL 1 57
BOLT
M4*16 4
21 BOTTLE BRACKET 2 58
SCREW
ST4.0*20 2
22 UPRIGHT COVER 2 59 LOCK WASHER 6 3
23 LEFT BACK COVER 1 60
LOCK WASHER
8 14
24 RIGHT BACK COVER 1 61
LOCK WASHER
10 2
25 SIDE RAIL 2 62 SPRING WASHER 8 6
26 RUNNING BELT 1 63 FLAT WASHER 8 6
27 BELT 1 64 COMPUTER 1
28 BLUE CUSHION PAD 4 65
BOTTOM CONTROL
BOARD
1
29 BLACK CUSHION PAD 4 66 PULSE WITH SWITCH 1
30 TRANSPORT WHEEL 2 67 PULSE WITH SPEED 1
31 FOOT PAD 4 68 MAGNETIC SENSOR 1
32
ADJUSTABLE FOOT
PAD
2 69 COMPUTER UP WIRE 1
33
RING PROTECTING
WIRE PLUG
2 70
COMPUTER MIDDLE
WIRE
1
34 POWER WIRE BUCKLE 1 71 COMPUTER BOTTOM 1
