ASSEMBLY INSTRUCTIONS
TOOLS:
5# ALLEN WRENCH 5mm 1pcs
WRENCH W/SCREW DRIVERS=13, 14, 15 1pcs
Note: Do not plug into the mains power before completing the assembly
ASSEMBLY STEP ONE:
ASSEMBLY STEP TWO:
ASSEMBLY STEP THREE:
Lift up the computer section and
upright posts as arrow shows.
Note: When you insert the pole
sections ensure that the wires
do not get caught and become
damaged.
Slide Left upright (3) onto MAIN
FRAME (1)
To attach the upright posts (3) to the
frame use bolt (41) and lock washer
(60) Using the 5# Allen wrench
Note: Support the Left upright
with your hand to avoid injury.
Open the carton and remove all foam and
cardboard packaging. Place the treadmill on
the ground as per diagram
.
To Next Page
