Evolabel T63 - Overview; Component Identification

OVERVIEW
D43
2
3
4
5
6
7
1 - Print head handle
2 - Print head
3 - Inner paper guide
4 - Status beacon
5 - Outer paper guide
6 - Rewinder paper
pinch
7 - Rewinder pinch
release
8 - Rewind unit
T43/ T63
8
1
9
10
11
D43/ T43/ T63
9 - Ribbon rewind
shaft
10 - Ribbon unwind
shaft
11 - Power switch
