Evolabel T63 - User Interface Overview

1 - Start / Stop button
2 - Active message
button
3 - Menu bar
4 - Layout preview
5 - Test print button
TOUCH PANEL
5
3
4
6
5
2
1
7
6 - Active messages
popup window
7 - Reset button
OVERVIEW
CONTROL PANEL
5
1
23
4
1 - Test print button
2 - Reset button
3 - Stop button
4 - Start button
5 - Status LEDs
