6
K - Card thickness adjustment gauge
L - Cleaning roller
M - Printer dust filter
N - Thermal print head
O - Side panel opening mechanism
P - Space for double-sided printing activation key
Q - Heating head
R - Axles
S - Control panel
T - Jam-clearing wheel
U - Card leveler
V - Dust filter for the lamination module
W - Power cable socket
X - Lamination module serial number label
Y - Printer serial number label
NOTE
Your machine may be supplied with an LCD screen instead of the control panel. Please refer to the LCD screen user guide on how to operate it.
!
Access to the side panels of the machine and the option module installation/removal areas is restricted to your retailer/installer or to experienced
users. The machine should always be disconnected from the power supply (unplugged) before carrying out any work on it.
Please watch the getting started video described in the following chapter.
