Evolur aurora - CRIB ASSEMBLY - SIDE PANEL ASSEMBLY; Attach Side Panels to Footboard

10
www.evolurbaby.com/help
2
CRIB ASSEMBLY – SIDE PANEL ASSEMBLY
2a. To assemble the
Left Panel (5) and
Right Panel (4) of
the Crib, align
them to the
Footboard (1) as
shown in figure.
2b. Insert the Bolts
(B) inside the
holes provided at
the top and the
lower end.
2c. Tighten all the
four Bolts (B)
using the Allen
key (C).
(1)
(5)
(4)
x 4 (1-1/2”)
B
