3) INSTALLATION OF AN OUTDOOR BELL
INSTALLATION POSITION
Warning: Protect the camera lens from direct sunlight. If the camera is intensively
illuminated by street lights or a light object in the dark, it is necessary to install a
lamp near the bell to improve the camera's sensing!
INSTALLATION OF THE DOORBELL
1) Drill 4 holes in the wall for mounting the bracket. (Or use the prepared 3M
adhesive tape to fix the holder)
2) Fix the bracket to the wall with screws or 3M tape
3)
A
ttach the bell to the bracket
4) Screw the screw on the left side to secure the Bell and Battery!
Warning: After installing the doorbell, use the side screw to secure the doorbell
battery as shown in Figure 4 to prevent misconnection of the battery power supply.
