10) AC/DC WIRING INSTRUCTIONS
Note: The external power supply must meet the following parameters: AC: 8-
24V/2A, DC: 8-36V/2A
Screw the eyelets of the
attached wires to the
terminal
Add clamps to the
attached wires, ideally
lever clamps, so as not to
damage the wires.
Connect a power supply
with the correct polarity
in the case of DC to the
terminals.
11) NOTICE
1) Do not place the monitor near areas with a strong magnetic field.
2) Do not directly spray water or other liquids on the monitor.
3) Do not hit the display or the bell hard.
4) Do not expose it to sunlight or place it under strong reflected light.
5) Do not install the monitor near ammonia and toxic gases.
6)
Th
ere is high voltage inside the system. Do not disassemble this device randomly.
7) Do not use detergents or other chemical solvents to wipe the bell and display,
only a dry cloth.
8)
I
t is recommended to place the screen at a height greater than one metre.
9)
I
f the machine breaks down, do not disassemble it yourself. Instead, send it to
your local service centre for maintenance or contact our company directly:
servis@evolveo.com
TIP
: If the antenna is erected during use, it will reach its
longest range.
