Issue

3.0.G

XHub

3 Version 3.03 - Technical Reference Manual

EVS Broadcast Equipment – July 2011

2.3 REAR PANEL

2.3.1 OVERVIEW

Number Element

1 Power supply 2 (IEC connector)

2 Power supply 1 (IEC connector)

3 Configuration DIP switch matrix

4 Status LED

5 Speed LED

6 Link connector

7 Branch status LEDs

8 Input connectors

9 Output connectors

2.3.2 CONFIG DIP SWITCH MATRIX

All 8 switches must be up for normal operations.

2.3.3 LINK CONNECTOR

For EVS use only.
