©2015GoodmanManufacturingCompany,L.P.
ZoneControlFeatures
Atotaloffour(4)green
pulsingLED’sareprovidedto
indicateifacommunication
linkhasbeenestablished
betweeneach
communicatingtstat,and
thecommunicatingHVAC
system.
Aseriesofrapid andrandom
pulsesindicateasuccessful
commlink anddata
transmission.
(LED’s19,20,21,and22)
CommunicatingLED’s
