Exalto MD1 232BD User Manual

15 16 17 12 11 3 23
9
8 7 2 4 22 10
19
18 23
21
20 13 1
14
24
6
3
11
5
REVISIONS
REV. DESCRIPTION DATE NAME
A Did Severals chances about Bolt & Nuts 12-3-2021 RE
Pos. Park/QTY. Description PartNo/Note Material Weight
24 1 XP2 motor 12Volt 30Nm 2100.3012 - 1.300
23 2 Nut M8 0934A408 1.4401 - SS316 0.005
22 2 circlip 6mm 6799A4006 1.4401 - SS316 0.000
21 1 Wishoekschijf sticker 2100.931 PE High Density 0.000
20 1 Wishoekschijf 2100.930 1.0037 (S235JR) 0.269
19 2 PA6.6 bearingØ8×10×10 2100.926 PA66 - GF30 0.000
18 1 Wishoekpen 2100.920 1.4401 - SS316 0.013
17 1 Weathercap M20 2100.361 Rubber 0.005
16 1 Washer 0125A408 1.4401 - SS316 0.002
15 1 Self-locking nut 0985A408 1.4401 - SS316 0.006
14 3 Hexagon socket head cap screw 0912A406016 1.4401 - SS316 0.007
13 3 SS Flathead bolt M6×16 0965HA406016 1.4401 - SS316 0.005
12 1 circlip 12mm 0471A2012 1.4401 - SS316 0.000
11 2 filling ring 2100.400 1.4401 - SS316 0.001
10 1 Connecting rod Ø10 L=85mm 2100.936 - 0.050
9 1 Sluitplaat rvs 235KK-KJ zwart gecoat 2100.480 1.4401 - SS316 0.038
8 2 Sluitplaat Nitril 223BS 50mm 2100.490 NBR 0.005
7 1 Idler spindle M8, Bulkhead fitting wd=20mm 2100.446 1.4401 - SS316 0.025
6 1 Wisas Ø12 + lever st38 wd=20 2100. 364 1.4401 - SS316 0.131
5 1 Liner M20x1mm 2100.326 Brass 0.092
4 1 Nut M8 flat 0439A408 1.4401 - SS316 0.003
3 2 Nut M20x1 2100.350 1.4401 - SS316 0.014
2 1 Wisserbehuizing wisas zijde 2100.890 1.0577 - S355J2 0.775
1 1 Wisserbehuizing Motorzijde 2100.895 1.0577 - S355J2 1.009
7.2 Parts list
Pos Q T Y. Description Part nr/Note
1 1 Half Wiper Shell Motor Side 2100.895
2 1 Half Wiper Shell Spindle Side 2100.890
3 2 Nut M20x1 2100.350
4 1 Nut M8  at 0439A408
5 1 Liner M20x1mm bh = 20 2100.326
1 Liner M20x1mm bh = 35 2100.321
1 Liner M20x1mm bh = 55 2100.327
1 Liner M20x1mm bh = 75 2100.328
1 Liner M20x1mm bh = 100 2100.329
1 Liner M20x1mm bh = 125 2100.331
6 1 Driven spindle + lever bh = 20 2100.364_A
1 Driven spindle + lever bh = 35 2100.360_A
1 Driven spindle + lever bh = 55 2100.366_A
1 Driven spindle + lever bh = 75 2100.368_A
1 Driven spindle + lever bh = 100 2100.370_A
1 Driven spindle + lever bh = 125 2100.372_A
7 1 Idler spindle bh = 20 mm KK/BD/BS 2100.446
1 Idler spindle bh = 35 mm KK/BD/BS 2100.441
1 Idler spindle bh = 55 mm KK/BD/BS 2100.447
1 Idler spindle bh = 75 mm KK/BD/BS 2100.448
1 Idler spindle bh = 100 mm KK/BD/BS 2100.449
1 Idler spindle bh = 125 mm KK/BD/BS 2100.451
8 2 Coverplate Nitril 50mm 2100.490
9 1 Cover plate SS 50mm black 2100.480
10 1 Connecting rod Ø10 L=85mm 2100.936
11 2 Plain washer s.s. M12x1,0 2100.400
12 1 circlip 12mm 0471A2012
13 3 SS Flathead bolt M6×16 0965HA406016
14 3 Hexagon socket head cap screw M6x12 0912A406012
15 1 Self-locking nut M8 0985A408
16 1 Ring-DIN125A-A4-M8 0125A408
17 1 Weathercap M20 2100.361
18 1 Linking pen M8 235KK/KD/KG/KJ/B 2100.920
19 2 PA6.6 bearingØ8×10×10 2100.926
20 1 Arc disc for wiper235KK/KD/KG/KGV/KJB/BD 2100.930
21 1 Sticker arc disc 235KK/KD/KG/KJ/BD 2100.931
22 2 circlip 6mm 6799A4006
23 2 Nut s.s. M8 A4 din934 0934A408
24 1 Exalto XP2 wiper motor 12V 30Nm 2100.3012
1 Exalto XP2 wiper motor 24V 30Nm 2100.3024
19
Exalto type 232BD
MANUAL WIPER SYSTEMS
