Exalto MD1 232BD User Manual

2. Technical data
2.1 General
• Product Exalto windscreen wiper
• Type 232BD (Bulkhead fi tting, Disc adjustable, Closed
housing)
• Catalogue numbers 2157.30 /-.32/-.35/-.40/-.45/-.50 (12V)
2158.30/-.32/-.35/-.40/-.45/-.50 (24V)
2.2 Electrical data 12 Volt
• Torque (max.) 32 Nm
• Voltage 12 Volt
• Current 3 A
• Power consumption (max.) 36 W
• Number of revolutions Low speed 38 rpm, high speed 56 rpm
• Recommended cable 5 wires 1½ mm² (16 g) or 2½ mm² (14 g) up to 10 m long
• Recommended fuse 6 A slow blow
• Grounding Insulated earth return
2.2 Electrical data 24 Volt
• Torque (max.) 32 Nm
• Voltage 24 Volt
• Current 1,5 A
• Power consumption (max.) 36 W
• Number of revolutions Low speed 38 rpm, high speed 56 rpm
• Recommended cable 5 wires 1½ mm² (16 g) or 2½ mm² (14 g) up to 10 m long
• Recommended fuse 4 A slow blow
• Grounding Insulated earth return
2.3 Mechanical data
• Dimensions L x w x h = 199 x 123 x 114 mm
• Shaft diameters Drive shaft Ø 20 mm/support shaft Ø 8mm at 50 mm ctrs
• Mounting In bulkhead or glass (20, 35, 55, 75, 100 or 125 mm)
• Bearing Bronze housing, self-lubricating
• Wiper arms Model MD1 (PU) up to 750 mm
• Wiper blades Up to 800 mm
• Wipe arc 40°-90°, adjustable per 5° increments
• Weight Approx. 2,50 kg
7
Exalto type 232BD
MANUAL WIPER SYSTEMS
