Exalto MD1 232BD User Manual

3. Determine the place where the wiper is to be installed. The dimensions are shown
below. The wiper can be installed in any position above or below the window.
4. Place the windscreen wiper in the pre-drilled holes of the bulkhead (see fi gure). A rubber sealing
gasket must be placed at both sides of the bulkhead.
• The wipe arc-line closest to the intersection, shows the wipe arc;
• Find in the table below the vertical displacement of the blade (H);
Now the wiper blade length can be calculated: Length of wiper blade = 0.9 * 2 * (E-H).
90°
86
103
117
132
146
161
176
190
205
220
234
249
264
278
293
263
250
105
85°
92
79
119
132
145
158
197
184
171
210
223
236
94
80°
82
70
105
117
129
140
175
164
152
187
199
211
222
234
83
75°
73
62
93
104
114
124
155
145
135
165
176
186
196
207
73
70°
63
55
81
90
100
109
136
127
118
145
154
163
172
181
63
65°
55
47
71
79
86
94
117
110
102
125
133
141
149
157
54
60°
47
40
60
67
74
80
100
94
87
107
114
121
127
134
45
55°
40
34
51
57
62
66
85
79
74
90
96
102
107
113
36
50°
33
26
43
47
52
56
70
66
61
75
80
84
89
94
30
45°
27
23
35
38
42
46
57
53
50
61
65
68
72
76
25
40°
21
19
26
30
34
37
45
43
40
48
51
54
57
60
400
Armlength (L)
350
300
450
500
550
600
750
700
650
800
850
900
950
1000
Determining the vertical displacement of the wiper blade
Wipe arc
Vertical displacement of the blade (H)
Units in mm
A ention!
When installing the wiper, reserve space for a housing or cover.
Bearing
Dogbone
Nut M10
Tightening 33Nm/24ft. lbs
Nut M8
Tightening 17Nm/12ft. lbs
Hexagon nut
tightening torque 26Nm/19ft. lbs
Glass or Bulkhead
Rubber sealing plate
Pin
Hexagon locking nut
tightening torque 16.3Nm/12ft. lbs
Stainless steel sealing plate
Bearing
Rubber sealing plate
Glass or Bulkhead
Glass or Bulkhead
Rubber weathercap
Nut M8
tightening torque 16.3/12ft. lbs
M8 washer
Tightening 16.3Nm/12ft. lbs
9
Exalto type 232BD
MANUAL WIPER SYSTEMS
