Copyright © 2013 MAT Industries, LLC
E106534
15 - ENG
PARTS LIST & EXPLODED VIEW
PRESSURE WASHER ITEM #E106527
ITEM
#
KIT
#
PART
NO.
QTY DESCRIPTION
ITEM
#
KIT
#
PART
NO.
QTY DESCRIPTION
1 E104421 1 Assembly, Engine 212cc Rato,
R210
16 E104102 1 Assembly, Wand & Quick Con-
nect, 15.125"
2 E104755 1 Assembly, Pump, Brass Head,
AXB28
17 E104846 2 Wheel, 10"
3 E104815 1 Assembly, Chemical Hose 18 2 Washer, Large, 8mm
4 4 Bolt, Socket Head Cap M8 X 1.25
X 30mm
19 8 Nut, M8 X 1.25 Nyloc
5 4 Washer, Lock 8 mm 20 E104975 1 Holder, Wand
6 4 Washer, Flat 8mm X 19mm 21 E104851 1 Axle, Frame
7 4 Screw, Hex Head M8 X 1.25 X
35mm
22 2 Bolt, Hex Flange Head M8 X 1.25
X 45mm (Yellow Zn)
8 E104817 1 Nozzles, 3.5 Qc, 5 Pack With
Soap Nozzle
23 E104967 1 Assembly, Pull Pin With Spring
And Knob
9 E104850 1 Frame, Panel, Handle 24 E100240 2 Isolator, Foot (Dia. 60mm X
28mm Tall)
10 4 Screw, Hex Socket Button Head
Cap 6mm X 1.0 X 25mm
25 2 Screw, Hex Flange Head M6 X
1.0 X 20mm (Yellow Zn)
11 4 Washer, Lock 6mm 26 E104849 1 Frame, Panel, Lower
12 2 Washer, Flat 6mm X 12mm 27 2 Screw, Phil Head Pan Head M5 X
0.8 X 35mm (Yellow Zn)
13 E104853 1 Frame, Tube, Upper Handle 28 2 Nut, M5 X 0.8 Nyloc
14 E104816 1 Assembly, Hose, 1/4", 25 Ft, 20
MPA Rating
29 1 Assembly, Frame,
PWZ0163100.02
15 E104822 1 Gun, Pressure Washer, Ergonom-
ic With Color Touch Points
Note: Any part number eld without a number listed is not available.
Descriptions are provided for reference only.
