ASSEMBLY INSTRUCTIONS
CARTON CONTENTS
Engine Frame and
Wheel Assembly
High Pressure
Hose
Spray Gun
Gatling Spray Wand
Handle
Chemical
Hose
Bagged Parts
Engine
Manual
Operation
Manual
1. Locate and remove all loose parts
from the carton.
2. Cut four corners of the carton from
top to bottom and lay the panels
fl at.
3. Place the panel as shown and
align
the screw bosses on the panel
with the large holes in the handle.
Secure handle to panel assembly
with four screws supplied.
Large holes
Panel
Screw
Bosses
Accessory
Storage Panel
Cover
Screws
"J" Bolts
Knobs
Panel Assembly
Cleaning Tool
To Next Page
