Excelsior Rockler - Parts List; Component Identification and Quantity

12
Distributed by Rockler Companies, Inc.
4365 Willow Dr. Medina, MN 55340
33207
Rev 12/21
1-800-279-4441
www.rockler.com
PARTS LIST
Quantity
1
Lathe Bed 1
2
Semicircle Head Screw 2
3
Retaining Plate 1
4
Quill Handwheel 1
5
Tailstock 1
6
Quill Lock Handle 1
7
Tailstock Lock Lever 1
8
Tail Axis 1
9
Taper Rod 1
10
Bearing Ball 1
11
Cup Center 1
12
M2 Spur Center 1
13
Faceplate 1
14
Headstock Spindle 1
15
Bearing Ball 1
16
Retaining Ring 1
17
Retaining Ring 1
18
Bearing Ball 1
19
Headstock 1
20
Rear Belt Access Cover 1
21
Screw 3
22
Headstock Wheel 1
23
Side Belt Access Cover 1
24
Hex Socket Set Screw 1
25
Drive Pulley 1
26
Drive Belt 1
27
M8 x 25 Hex Socket Head Screw 5
28
M6 x 10 Hex Socket Set Screw 1
29
Motor Pulley 1
30
Hex Socket Head Screw 3
Quantity
31
Belt Tension Lever 1
32
Motor 1
33
Belt Tension Lever Lock Handle 1
34
Retaining Ring 12 2
35
Tool Rest 1
36
Tool Rest Banjo 1
37
Bolt 1
38
Lock Plate 1
39
Hex Nut 1
40
Banjo Lock Lever 1
41
Tool Rest Lock Handle 1
42
Bolt 1
43
Lock Plate 1
44
Hex Nut 1
45
Power Cord 1
46
Plate 2
46A
Washer 2
46B
Screw 2
47
Switch 1
48
Washer 4
49
Spring Washer 8
50
Rubber Washer 4
51
Switch Box 1
52
Washer 4
53
Retaining Ring 10 1
54
Tailstock Quill 1
55
Bolt 1
56
Handle 1
57
Moving Knob 2
58
Stationary Knob 2
