Exerpeutic 1110 - Parts List

Part # Description Qty Part # Description Qty
001 Rear Frame 1 035 Magnet Bracket 1
002 Front Frame 1 036 Magnet 1
set
003 Rear Stabilizer 1 037 Sensor with Wire 1
004 Computer Bracket 1 038 Flywheel 1
005 Seat Post 1 039 Belt Wheel with Crank Axle 1
006 Seat Cushion 1 040 Bearing Bracket A 2
007 Left Pedal 1 041 Bearing Bracket B 2
008 Right Pedal 1 042 Bearing 6003RS 4
009 Computer 1 043 C-ring Ø17 6
010 Oval Wire Plug 27x23xØ8x13H 1 044 Belt Wheel 1
011 Front Stabilizer End Cap 2 045 Bearing 6000Z 2
012 Seat Post Plastic Bushing 1 046 Axle 1
013 Tension Control Knob 1 047 Eyebolt 2
014 Seat Height Adjustment Knob
M16
1 048 Tension Bracket 2
015 Connection Wire A 1 049 Washer Ø6.2 4
016 Front Frame Support Tube 1 050 Nylon Nut M6 2
017 Computer Post 1 051 Nut M10 3
018 Left Shroud 1 052 Washer Ø10.2xØ25 2
019 Right Shroud 1 053 Wave Washer Ø17 1
020 Top Shroud 1 054 Idle Wheel Axle 1
021 Round Plastic Bushing 6 055 Nylon Nut M10 1
022 Safety Pin A 1 056 Bearing 6902Z 2
023 Left Crank 1 057 Axle Ø15.8x94.5L 1
024 Right Crank 1 058 Hexagon Socket Bolt M8x15 5
025 France Nut 2 059 Rubber Cushion 1
026 Crank Cover 2 060 Washer Ø8.2xØ25x2.0t 2
027 Phillips Round Head Drilling
Screw M4x20
7 061 Screw M6x10 6
028 Phillips Round Head Tapping
Screw M4x20
4 062 Safety Pin B 1
029 Hexagon Nut Cap M8 5 063 Screw M4x10 1
030 Curve Washer Ø8.2xØ22.2 6 064 Wave Washer Ø15 1
031 Hexagon Socket Bolt M8x45L 4 065 C-ring Ø15 1
032 Flat Washer Ø8.2xØ25x1.5t 8 066 Nut M6 1
033 Flat Washer Ø8.2 3 067 Hexagon Socket Bolt
M8x100L
1
034 Nylon Nut M8 4 068 Screw M5x20 1
5
PARTSLIST
