Exerpeutic 1111 - Front and Rear Stabilizers Installation

4 Bolts (M8x70)
4 Curve Washers (Ø8)
4 Cap Nuts (M8)
Position the Front Stabilizer (2) in front of the Front Main Frame (5) and align bolt
holes. Attach the Front Stabilizer (2) onto the front curve of the Front Main Frame
(5) with two M8x70 Bolts (30), two Ø8 Curve Washers (25), and two M8 Cap Nuts
(32). Tighten cap nuts with the Multi Hex Tool with Phillips Screwdriver provided.
Position the Rear Stabilizer (4) behind the Rear Main Frame (3) and align bolt
holes. Attach the Rear Stabilizer (4) onto the rear curve of the Rear Main Frame
(3) with two M8x70 Bolts (30), two Ø8 Curve Washers (25), and two M8 Cap Nuts
(32). Tighten cap nuts with the Multi Hex Tool with Phillips Screwdriver provided.
2. Front and Rear Stabilizers Installation
Tool:
Multi Hex Tool with
Phillips Screwdriver
Hardware:
10
