No. Description Qty No. Description Qty
049 Bolt M8x10 4 074 Power Supply Cable L=300 mm 1
050
Extension Sensor Wire I
L=650 mm
1 075 Hexagon Nut 1/2” 1
051 Extension Sensor Wire L=600 mm 1 076 Adapter L=2000 mm 1
052 Screw ST2.9x12 2 077 Front Stabilizer End Cap Ø60 2
053 Sensor with Wire L=300 mm 1 078 Front Stabilizer Ø60x1.5x580 1
054 Front Post Cover 1 079 Bolt M6x45 2
055
Extension Hand Pulse Sensor
Wire II L=1200 mm
1 080 Transport Wheel Ø23xØ6x32 2
056
Phillips Self Tapping Screw
ST4.2x20
6 081 Nylon Nut M6 2
057 DC Motor with Wire L=300 mm 1 082 Bolt M8x20 1
058 Screw ST4.2x25 6 083 Idler Arm 1
059 Cover Cap Ø40xØ25x10 2 084 Big Washer Ø8xØ20x2 1
060 Right Cover 672x79x448 1 085 Nylon Nut M8 1
061 Right Foot Pedal (YH-63X) 1 086 Bearing 6000-2Z 2
062 Crank with Belt Pulley Ø240 1 087 Washer Ø10xØ14x1.0 2
063 Left Foot Pedal (YH-63X) 1 088 Bolt M6x10 1
064 Washer Ø24xØ40x3.0 1 089 Spring Ø17x80xØ2.5 1
065 Bearing Nut I 15/16" 1 090 Belt PJ360 J6 1
066 Ball Bearing 2 091 Nut M6 2
067 Bearing Cup 2 092 Spring Washer Ø6 2
068 Bearing Nut II 7/8" 1 093 Tension Bracket 2
069 Washer Ø23xØ34.5x2.5 1 094 Adjustable Bolt M6x36 2
070 Hexagon Nut 7/8” 1 095 Nut M10x1.0x6 2
071 Left Cover 672x83x448 1 096 Flywheel Ø230 1
072 Magnetic Brake Cable L=280 mm 1 097 L Shape Knob M6x1.5 1
073 Front Main Frame 80x40x2 1
7
PARTS LIST
