Exerpeutic 1115 - Parts List

No. Description Qty No. Description Qty
001 Handrail End Cap Ø32x1.5 2 025 Bushing 2
002 Bolt M6x70 4 026 Rear Main Frame 1
003 Washer Ø6xØ12x1.0 5 027 Side Triangle Knob M12 1
004 Left Handrail Ø32x1.5x1085 1 028 Bottom Triangle Knob M12 1
005 Backrest 465x465x135 1 029
Extension Hand Pulse Sensor
Wire I L=1300 mm
1
006
Hand Pulse Sensor with Wire
L=1150 mm
2 030
Phillips Self Tapping Screw
ST4.8x20
2
007 Screw ST4.2x30 2 031 Right Decorate Cover Ø60 1
008
Handrail Foam Grip
Ø31xØ37x230
2 032 Left Decorate Cover Ø60 1
009 Bolt M6x35 2 033 Screw ST4.8x25 3
010 Big Curve Washer Ø6xØ16x1.5 6 034 Rear Stabilizer End Cap Ø60 2
011 Cap Nut M6 2 035 Cap Nut M8 4
012 Right Handrail Ø32x1.5x929 1 036 Big Curve Washer Ø8xØ20x2.0 5
013
Extension Hand Pulse Sensor
Wire L=300 mm
1 037 Bolt M8x70 4
014 Wire Grommet Ø12.1 2 038 Rear Stabilizer Ø60x1.5x580 1
015 Seat Sliding Tube 53x23x2 1 039 Bolt M8x15 15
016 Seat 430x330x90 1 040 Washer Ø8xØ16x1.5 18
017
Back and Seat Support Bracket
53x23x2
1 041 Hexagon Nut M10xH5 1
018 Big Washer Ø6xØ18x1.5 4 042 Adjustable Leveler M10 1
019 Bolt M6x20 4 043 Computer M7-570 1
020 Armrest 250x110x45 2 044
Extension Hand Pulse Sensor
Wire III L=650 mm
2
021
Right Handrail Support Tube
Ø25x1.5
1 045 Bolt M5x10 4
022 Bolt M6x50 4 046 Bolt M5x15 2
023
Left Handrail Support Tube
Ø25x1.5
1 047 Bottle Holder 1
024 Bolt M6x15 4 048 Front Post 70x30x1.5 1
PARTS LIST
6
