Exerpeutic 4200 - Assembly

1. Front and Rear Stabilizers Installation
Position the Front Stabilizer (15) in front of the Main Frame (39) and align bolt holes.
Attach the Front Stabilizer (15) onto the front curve of the Main Frame (39) with two
Hexagon Socket Pan Head Cap Bolt (9), two Flat Washer (10). Tighten Hexagon Socket
Pan Head Cap Bolt(9)with the Allen Wrench(30) S6 Provided.
Position the Rear Stabilizer (12) behind the Main Frame (39) and align bolt holes.
Attach the Rear Stabilizer (12) onto the rear curve of the Main Frame (39) with two
Hexagon Socket Pan Head Cap Bolt (9) and two Washers (10). Tighten Hexagon
Socket Pan Head Cap Bolt(9)with the Allen Wrench(30) S6 Provided.
Hardware:
ASSEMBLY
8
(10) Washer
4PCS
(9)Hexagon Socket Pan Head Cap Bolt
4PCS
(30) Allen Wrench
S6
