PARTS LIST
No.
Description
Qty
No.
Description
Qty
1
Backrest
1
30
Foot Bar Oval End Cap
2
2
Backrest Frame
1
31
Foot Cap
4
3
Adjustable Boom
1
32
Flat Washer Ø13xØ6.5x1.5
6
4
Foot Bar
1
33
Hex Bolt M6x40mm
6
5
Rear Rod
1
34
Square End Cap
6
6L
Left Handlebar
1
35
Upper Bed Frame End Cap
1
6R
Right Handlebar
1
36
Rubber Pad
2
7
Steel Heel Holder Bracket
2
37
Lower Bed Frame Bushing
2
8
Rear Frame
1
38
Knob
1
9
Front Frame
1
39
Flat Washer Ø30xØ10.5x0.5
2
10L
Left Pivot Arm
1
40
Flat Washer Ø25xØ10.5x2.0
3
10R
Right Pivot Arm
1
41
Spring Knob
1
11
Adjustable Handle
1
42
Nylon Nut M8
10
12
Handlebar Foam Grip
4
43
Flat Washer Ø16xØ8.5x2.0
1
13
Front Rod
1
44
Metal Bushing
1
14
Rubber Heel Holder
2
45
Hex Bolt M8x53mm
1
15
Socket Hex Bolt M8x55mm
3
46L
Left Plastic Cover
1
16
Flat Washer Ø25xØ8.5x2
3
46R
Right Plastic Cover
1
17
Plastic Spacer
1
47
Socket Hex Bolt M10x30mm
1
18
Plastic Round End Cap
1
48
Nylon Nut M10
1
19
Flat Washer Ø16xØ8.5x1.5
20
49
Hex Bolt M5
1
20
Socket Hex Bolt M8x58mm
6
50
Nylon Nut M5
1
21
Flat Washer Ø25xØ8.5x1.5
1
51
Hex Bolt M8
1
22
Rod Cap
1
52
Handlebar Round End Cap Ø25
2
23
Cup Holder
1
53L
Left Handlebar Cover
1
24
Cap Nut M8
1
53R
Right Handlebar Cover
1
25
Square End Cap □38
3
54
Self-Tapping Phillips Screw
ST3.5x13
6
26
Safety Pin Ø8x63.5mm
1
55
Self-Tapping Phillips Screw
ST3.5x16
2
27
Socket Hex Bolt M8x65mm
2
56
Phillips Screw M5x18mm
1
28
Socket Hex Bolt M8x20mm
7
57
Button
1
29
Plastic Washer
4
58
Handlebar Cap
1
