Exerpeutic 475SL - Assembly; Setting Up the Frame

10
This product weighs more than 44lbs/20kgs and should
be assembled and moved by two or more people.
ASSEMBLY
Step 1
Setting Up the Frame:
1A. Stand the frame up by pulling the Front and Rear Frames (9, 8) as far apart from each other
as possible. Then insert the Safety Pin (26) into the hole on the right side of the frame to lock the
Front and Rear Frames (9, 8) together.
1B. Attach the two Rubber Pads (36) onto the Cross beam of the Front Frame (9).
Hardware:
(26) Safety Pin 1PC
