. Remount the right side cover that was removed from the UPS cabinet in
Step 10 to the right side of the last battery cabinet. Use the original hardware
provided in the joining kit.
. Remount the top cover of the battery cabinet by offsetting the cover toward
the back. Push it forward so that the spring latch engages the frame top.
Secure the cover using the original hardware.
. Close the top cover of the UPS unit.
. Continue to Electrical Installation" on page 42.
If you are installing an optional PDM, continue to page 46.
All cabinets must be secured to keep them from moving after installation
is complete. Secure the cabinets by bolting the cabinets to the cabinet mounting
plate. Failure to do so violates safety rules and results in the unit losing its safety
agency approvals.
