Operation
x3/4inchhexwasherheadscrewsandthree
1/4-20inchnylocnuts.
21.Slidethelowerendofthetubeassemblyoverthe
bloweroutletandalignthenotchwiththetube
latch.Latchthetubetotheblower.
22.Oneachside,installtheROPSpinintothehole
belowtheROPSpivot.
23.Installoneremovablecasterweightoneachcaster
armasshowninFigure16.
g037183
Figure16
1.Bolt3.Washer
2.Knob
4.Casterweight
24.Inserttheboltthroughthebracketholeandinstall
thewasherandknob.
25.Tightentheknobonweightassemblyuntilthe
weightisclampedsecurelytothecasterarm.
Important:Forcorrecttractionand
stability,installtherequiredquantityof
counterbalanceweight(s)asspeciedin
theUltraVacOperator’smanual,setup
instructions,and/orcompletingkit.
Note:Theremovableweightsareheavy.Use
carewhenliftingthem.Makesurethatyoucan
holdthemsecurelybeforeliftingthem.Use
cautionwhenpositioningyourhandstothatyou
DoNotsetthemdownonyourhandsorngers.
Note:TheportionsoftheUltraVaccollection
systemthatarenotboltedtothemowerare
designedtobeinstalledorremovedintheir
entirety.DoNotoperatethemowerwithonlya
portionoftheUltraVacinstalled.
AfterOperation
GeneralSafety
•Parkmachineonlevelground,disengagedrives,
setparkingbrake,stopengine,removekeyor
disconnectsparkplugwire.Waitforallmovement
tostopandallowthemachinetocoolbefore
adjusting,cleaning,repairing,orstoring.Never
allowuntrainedpersonneltoservicemachine.
•CleanthemachineasstatedintheMaintenance
section.
•Frequentlycheckforwornordeteriorating
componentsthatcouldcreateahazard.Tighten
loosehardware.
