Operation
10.Positionthebeltcoveratanangleandslideit
underthemowerframe(seeFigure12).
g251520
Figure12
1.Blower
3.Mowerframe
2.Beltcover
11.Pushdownonthebackofthecoverandslideit
backwardsundertheblower.
12.Withthebeltcoverrestingonthedeck,slideit
forwarduntilitisseatedunderbothlipsonthe
deck.
g251531
Figure13
1.Blower3.Decklip
2.Beltcover
13.Installtheknobanditshardware.
14.Sliptheupperandthelowertubestogether.
15.Inserttheuppertubeintothehopperseal–
pushinthenpulloutsothatthesealisextended
outward.
16.Alignthedimpleontheuppertubewiththeend
ofhoppersealandcenterbetweenthetwoscrews
asshowninFigure14.Thescrewheadshould
beinstalledtotheinsideofthetubetoprovide
minimumobstructiontoow.
g007027
Figure14
1.Dimple
17.Setthedeckinlowestcuttingposition.
18.Slidethelowertubeontotheblowerandattach
thelatches.(Makesurethattheuppertubedoes
notmoveoutofalignment).
19.Ifthelowertubeisreplaced,drillthree1/4inch
holesinthelowertubeusingtheuppertubeholes
asreference(seeFigure15).Makesurethatthe
upperandthelowerendsareorientedproperly
asthetubesareassembled(partinglinesshould
roughlybelinedup).
g007028
Figure15
1.Drilltheholeshere
20.Removethetubesfromunitandassemblethe
upperandthelowertubesusingthree1/4-20
