Operation
g037999
Figure9
1.Hopperframepin
3.Hopperhinge
2.Seal(partiallyremoved
forclarity)
4.Airvent
5.Openthehopperandinstallthebags.Closethe
hopperandstretchtherubberlatchoverthehold
downrod.
6.Removethebeltcoverontherightsideofthe
deck.
7.Mountthebloweronthedeckbyinsertingthe
mountingpinintothetubeweldedtotherear
cornerofthedeck.UseFigure10todetermine
thepinlocationintheblowerframe.
g251519
Figure10
1.Mountingpin
4.48inchdecklocation(A)
2.Rollpin
5.60inchdecklocation(C)
3.52inchdecklocation(B)
8.Pivottheblowertowardsthedeckandpull
outwardonthelatchpin.Releasethelatchpin
whenitalignswiththeholeonthetabofthedeck
tolocktheblowerinthisposition.
9.Pushthespringloadedidlerinandslipthebelt
overthetopdecksheave.Thebeltshouldbe
routedasshowninFigure11.
g252500
Figure11
ViewfromT opofBlower
1.Springloadedidler
3.Decksheave
2.Impellersheave
