Safety
decal114-4466
114-4466
Non-REDandNon-SmartControllerEquippedModels
Only
1.Main,25A
3.Charge,25A
2.PTO,10A
4.Auxiliary,15A
decal115-9625
115-9625
SuspensionModels
1.Parking
brake—disengaged
2.Parkingbrake—engaged
decal116-5988
116-5988
AllExceptSuspensionModels
1.Parkingbrake—engaged2.Parking
brake—disengaged
decal116-8283
116-8283
1.Warning—readtheOperator'sManualforinstructions
ontorquingthebladebolt/nutto55-60ft-lb(75-81N-m).
decal116-8724
116-8724
AllLZEexceptEFIModels
AllLZS/LZXKawasakiModelsexceptREDEquipped
1.Throttle-fast4.Choke-off
2.Throttle-slow
5.PTO
3.Choke-on
